Plant Air Vibrator-Ball Type
Plant Vibrator · Ball Type
This VIBCO BV-320 is a heavy-duty pneumatic ball vibrator used to ensure the consistent flow of bulk materials like sand, cement, and aggregate in the bins and hoppers of concrete batch plants. It operates by using compressed air to rapidly rotate a hardened steel ball within a polished steel race, generating 480 lbs of force to prevent material bridging, rat-holing, and sticking. This part is a crucial replacement for maintaining plant efficiency and requires a lubricated air line for optimal performance and longevity.
Technical Specifications
Manufacturer Part Number
BV-320
Vibrator Type
Pneumatic Ball
Force Output
480 lbs @ 80 PSI
Vibration Speed
8,400 VPM @ 80 PSI
Air Consumption
17 CFM @ 80 PSI
Maximum Operating Pressure
80 PSI
Inlet Port
3/8 inch NPT
Outlet Port
3/8 inch NPT
Housing Material
Cast Iron
Sound Level
80 dBA
Weight
6.6 lbs
Key Features
- Generates 480 lbs of centrifugal force at 80 PSI
- Operates at 8,400 vibrations per minute (VPM) at 80 PSI
- Durable cast iron housing for harsh industrial environments.
- Designed for continuous duty cycles.
- Requires lubricated air for operation.
- Handles a maximum bin material weight of 4,800 lbs.
- Features a 3/8" NPT inlet and outlet port.
Fits These Mixers
Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. This vibrator is a direct replacement for the VIBCO BV-320 model. It is commonly used on aggregate bins, scale hoppers, and material chutes in concrete batch plants from various manufacturers, including Con-E-Co, Vince Hagan, and Stephens, to facilitate material flow.
All measurements ± standard manufacturing tolerance.
