Control Valve Cartridge

Control Valve Cartridge

This product is a direct-acting, screw-in hydraulic cartridge valve manufactured by HydraForce, part number SV08-47AW-O-N. It is designed to direct hydraulic fluid in concrete mixer applications, commonly used within Eaton RE control valve assemblies to manage functions like charge/discharge. When de-energized, the valve blocks the work ports while allowing flow from port 3 to 1. This replacement cartridge is essential for maintenance or repair of the mixer's hydraulic control system to restore proper functionality. The cartridge is made of steel with hardened internal components for durability and features Buna-N seals.

Key Features

• Solenoid-operated, 4-way, 3-position, tandem center spool design.
• Hardened precision steel spool and cage for long life.
• Fits industry-common VC08-4 (size 08) cavities.
• Rated for operating pressures up to 3000 PSI (210 bar).
• Allows a maximum flow rate of 3.0 GPM (11.4 lpm).
• Features Buna-N seals for standard hydraulic fluids.

Fits These Mixers

McNeilus, Terex, Con-Tech. Commonly found on the Eaton RE Control Valves used in rear discharge concrete mixers, including models from McNeilus and Kimble.

All measurements ± standard manufacturing tolerance.
