Bray Large Cylinder Mount Arm 8-12"

Bray Large Cylinder Mount Arm 8-12"

This cylinder mounting arm is a critical component for automating material flow in concrete batch plants. It securely connects a pneumatic actuator to a Bray butterfly valve, enabling the remote opening and closing of the valve. These assemblies are commonly used on aggregate bin gates, cement batchers, and water lines. This part is a necessary replacement for arms that have failed due to mechanical stress, vibration, or corrosion, ensuring the continued reliability of the batching system.

Key Features

• Designed to mount pneumatic actuator cylinders to Bray butterfly valves
• Compatible with large butterfly valves in the 8" to 12" size range
• Used for automating aggregate, cement, and water gates in batch plants
• Heavy-duty construction for durability in harsh plant environments

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits actuator and valve assemblies on concrete batch plants from major OEMs like Con-E-Co, Stephens Mfg., and Vince Hagan that utilize 8-inch, 10-inch, or 12-inch Bray butterfly valves.
