Conveyor Troughing Idler
Conveyor Idler · Troughing
This conveyor troughing idler is a critical component for the material handling system of a concrete batch plant. It consists of a reinforced steel frame holding three equal-length, sealed bearing rollers that form a 'trough' to guide the conveyor belt and contain the aggregate material being transported. These idlers are essential for preventing belt sag, reducing friction, and ensuring smooth, centered operation of the plant's conveyor. Replacement is necessary due to wear from continuous use, bearing failure, or damage, which can lead to belt misalignment and spillage. Vince Hagan offers these idlers for multiple belt widths (24", 30", 36", 48") and troughing angles (20°, 35°, 45°).
Technical Specifications
Component Type
Equal Troughing Idler
Roller Configuration
3 equal length rollers
Troughing Angles
20°, 35°, 45°
CEMA Ratings
B, C, D, E (Varies by part)
Material
Steel
Key Features
- Meets or exceeds CEMA B, C, D, or E load standards.
- Features three equal-length rollers with sealed ball bearings for a long, low-maintenance life.
- Reinforced frame design helps shed material to prevent build-up and corrosion.
- Minimal roll gap design helps prevent pinching and damage to the conveyor belt.
- Available in standard troughing angles of 20°, 35°, and 45° to suit different material loads.
- Designed for specific belt widths, including 24", 30", 36", and 48".
Fits These Mixers
Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits Vince Hagan concrete batch plant troughing conveyors. The specific part number required depends on the conveyor's belt width and troughing angle. For example, part number 25-6520 is for a 24-inch belt with a 35-degree trough. Also used on Con-E-Co batch plant conveyors; for example, part 1410265 is a CEMA C roller for a 30-inch belt.
All measurements ± standard manufacturing tolerance.
