Plant Conveyor Troughing Idler

Plant Conveyor Troughing Idler

This plant conveyor troughing idler is a critical component for the material handling systems in concrete batch plants. It supports the conveyor belt on the carrying side, creating a trough to prevent spillage of aggregates and other materials. This specific idler is built to CEMA B standards for light-duty applications and is designed for a 24-inch belt width with a 20-degree troughing angle. Replacement is necessary when existing idlers are worn, seized, or damaged, which can cause belt misalignment and premature wear. This idler features sealed ball bearings for a long, maintenance-free life.

Key Features

• Designed for 24-inch wide conveyor belts.
• Features a 20-degree troughing angle to contain material.
• Meets or exceeds CEMA B standards for load-bearing capacity.
• Equipped with three equal length, 4-inch diameter steel rolls.
• Maintenance-free sealed ball bearings for extended service life.
• Reinforced frame design helps shed material and prevent buildup.
• Minimal roll gap to prevent pinching the conveyor belt.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits concrete batch plant conveyors using 24-inch wide belts and CEMA B rated troughing idlers. Commonly found on equipment from manufacturers like Stephens Mfg., CMW, and other plants utilizing Precision idlers.

All measurements ± standard manufacturing tolerance.
