Air Filler - 3/4

Air Filler - 3/4

This is a 3/4-inch particulate air filter equipped with an automatic drain, commonly used in the aeration and pneumatic control systems of concrete batch plants. Its primary function is to protect sensitive downstream components, such as solenoid valves and air cylinders, from damage caused by moisture and solid debris in the compressed air supply. The automatic drain feature expels collected moisture without requiring manual intervention, making it a low-maintenance solution for ensuring consistent and reliable plant operation.

Key Features

• 3/4 inch female NPT inlet and outlet ports
• Features an automatic internal drain for maintenance-free moisture removal
• Removes liquid, vapor, and solid particles down to 5 microns
• Polycarbonate bowl allows for visual inspection of contaminants
• Maximum operating pressure of up to 150 PSI

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. This filter is a general-purpose component for the main compressed air supply system in various concrete batch plants, including those from Vince Hagan, Con-E-Co, and Stephens Mfg. It is installed in the air line to clean the air used for aeration systems, butterfly gates, and other pneumatic equipment.

All measurements ± standard manufacturing tolerance.
