Butterfly Valve-10"Bray Seat

Butterfly Valve-10"Bray Seat

This is a 10-inch replacement seat for a Bray butterfly valve, a critical component for controlling the flow of cement, fly ash, and other aggregates in a concrete batch plant. The seat creates a seal between the valve disc and body, preventing leaks and ensuring accurate material batching. Over time, the abrasive nature of concrete materials causes wear, and the seat must be replaced to restore the valve's bubble-tight shutoff capability and prevent costly material loss or contamination.

Key Features

• Designed for 10-inch Bray resilient seated butterfly valves.
• Creates a bubble-tight seal for reliable shutoff of powders and fine granulates.
• Tongue and groove seat design provides complete isolation of flowing media from the valve body.
• Replacement restores valve performance after wear from abrasive materials like cement and fly ash.
• Molded O-ring feature can eliminate the need for separate flange gaskets.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits 10-inch Bray butterfly valves used on concrete batching plants and associated equipment. Confirmed for use on equipment from Vince Hagan and Stephens Manufacturing.

All measurements ± standard manufacturing tolerance.
