Butterfly Valve Actuator - 2" & 3"

Butterfly Valve Actuator - 2" & 3"

This is a Bray Series 92 rack and pinion, opposed-piston pneumatic actuator, part number 92-0630-11300-532. It provides automated control for 2-inch and 3-inch butterfly valves by converting compressed air into rotary motion. It is commonly found on ready-mix concrete batch plants, often mounted to Bray butterfly valves on Badger water meters, making it a critical component for controlling water flow during concrete mixing. Its modular design allows for direct mounting and is suitable for both on/off and throttling applications.

Key Features

• Double-acting, rack and pinion opposed-piston design for automating quarter-turn valves.
• Designed for use with 2" and 3" butterfly valves.
• Operates on an air pressure range of 40 to 140 PSI (3 to 10 Bar).
• Features a die-cast aluminum alloy body and pistons for durability.
• Hardened alloy steel output shaft and pinion with zinc plating for corrosion protection.
• Buna-N seals for reliable performance.
• Commonly used on water meters in ready-mix concrete batch plants.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits 2-inch (Bray valve p/n 300200-11010119) and 3-inch (Bray valve p/n 300300-11010119) butterfly valves. It is commonly found mounted to Badger water meters on ready-mix concrete batch plants.

All measurements ± standard manufacturing tolerance.
