Butterfly Valve - 10"" Single Flange
Butterfly Valve · Single Flange
The WAM V1FS250 is a 10-inch single-flange butterfly valve, an essential component for intercepting the flow of powders and granular materials in concrete batching operations. It is typically installed at the discharge point of cement silos, fly ash hoppers, and dust collection systems to ensure accurate material cutoff. A replacement is necessary when the elastomer seal wears out, causing material leakage, or when the valve fails to actuate correctly, which can compromise batch accuracy and lead to material waste. The valve features a lightweight, high-pressure die-cast aluminum body and a splined shaft for easy mounting of manual, pneumatic, or electric actuators.
Technical Specifications
Diameter
10 inches (250 mm)
Body Material
Die-Cast Aluminum Alloy
Flange Type
Single Top Flange
Pressure Rating
Up to 0.2 bar (2.9 PSI).
Standard Disc Material
Cast Iron.
Standard Seal Material
Pre-stressed Elastomer
Key Features
- Manufactured by WAMGROUP, model V1FS250.
- 10-inch (250mm) diameter for standard concrete plant applications.
- Single-flange design (V1FS) for end-of-line mounting with a flexible sleeve.
- Lightweight, high-pressure die-cast aluminum semi-body.
- Interchangeable discs available in cast iron, stainless steel, or SINT polymer.
- Splined shaft design is compatible with a variety of actuator types.
Fits These Mixers
Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Direct replacement for WAM V1FS250 valves. Commonly used on the silo, hopper, and dust collector discharge points on concrete batch plants from OEMs like Vince Hagan, Con-E-Co, and Stephens. This valve is a direct cross-reference for Vince Hagan part numbers 01-1434 and 01-1429.
All measurements ± standard manufacturing tolerance.
