Butterfly Valve - 10" Double Flange-WAM

Butterfly Valve - 10" Double Flange-WAM

The WAM V2FS250GB is a 10-inch double flange butterfly valve used for intercepting gravity-fed or pneumatically conveyed dry materials like cement powder. It consists of two high-pressure, die-cast aluminum semi-bodies with identical top and bottom flanges, a cast iron swivel disc, and a pre-stressed elastomer seal. This valve is a necessary component for maintenance and control of material flow in silos, bins, and conveying systems. Its lightweight design and few components make it a cost-effective, easy-to-fit, and low-maintenance solution for controlling bulk solids.

Key Features

• Double flange design (V2FS) with identical top and bottom flanges.
• 10-inch (250mm) nominal diameter.
• High-pressure, die-cast aluminum alloy semi-bodies.
• Cast iron disc.
• Dust tight and pressure-proof up to 0.2 bar (2.9 PSI).
• Lightweight and easy to handle for simple installation and maintenance.
• Designed for powders and granular materials.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Used in concrete batch plants and other bulk solids processing plants for the interception of gravity-fed or pneumatically conveyed dry powders or granules. It is fitted beneath hoppers, bins, and silos or used to intercept screw conveyors or pneumatic conveying ducts. Compatible with WAM CP101 actuator.

All measurements ± standard manufacturing tolerance.
