Bray 4" Valve Lug Style

Bray 4" Valve Lug Style

This is a Bray 4-inch, lug-style butterfly valve, specifically the Series 21 model, commonly used for controlling the flow of water, admixtures, and cement dust in concrete batching systems. The lug body design allows for dead-end service, making it possible to remove downstream piping while the valve remains under pressure. This valve is a critical replacement part for plant maintenance, ensuring precise material measurement and preventing cross-contamination. Its robust construction is designed to handle the abrasive and demanding environment of concrete production.

Key Features

• Lug-style body for dead-end service capability.
• Tongue and groove seat design provides complete media isolation from the body and eliminates the need for flange gaskets.
• One-piece disc/stem design for high strength and a thin profile for improved flow characteristics.
• Provides bidirectional bubble-tight shutoff up to 150 psi (10.3 Bar).
• Primary and secondary seals prevent line media from contacting the stem or body.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits various concrete batch plant applications requiring a 4-inch lugged butterfly valve for water, admixture, or dust collection systems. Commonly used on equipment from manufacturers like Vince Hagan and Con-E-Co.

All measurements ± standard manufacturing tolerance.
