Butterfly Valve-4"Bray Iron Disc

Butterfly Valve-4"Bray Iron Disc

This is a Bray Series 30, 4-inch butterfly valve, commonly used for water applications in concrete batching plants, often paired with 4-inch water meters. The valve is designed for on/off control and features a durable cast iron body and a Nylon 11 coated ductile iron disc, making it a necessary replacement part for maintaining accurate water measurement and control. Its wafer-style design allows it to be installed between ANSI Class 125/150 flanges, and the EPDM seat provides a reliable, gasket-free seal.

Key Features

• Wafer style design fits between ANSI Class 125/150 flanges.
• Nylon 11 coated ductile iron disc for corrosion and abrasion resistance.
• Cast iron body with polyester coating for weather protection.
• EPDM seat provides a bubble-tight seal and eliminates the need for flange gaskets.
• High-strength 416 stainless steel stem.
• ISO 5211 top mounting for direct attachment of handles or actuators.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits Vince Hagan ready mix concrete batch plants, commonly used with 4-inch Badger water meters. Also found on Con-E-Co and McNeilus batch plants for cement and fly ash silo and weigh batcher applications.

All measurements ± standard manufacturing tolerance.

Product descriptions are drafted with automated tools and reviewed as time allows. While we work to keep them accurate, specifications and fitment should be confirmed with a Customer Service specialist at 800-745-3414 before purchase. Found an error? Let us know and we’ll fix it.
