Butterfly Valve-12"Bray

Butterfly Valve-12"Bray

This is a 12-inch Bray Series 20/21 butterfly valve, commonly used in concrete batch plants for managing the flow of abrasive materials like cement and fly ash from silos, or for water lines. The valve features a wafer-style body that fits between pipe flanges and is typically made of cast iron with a resilient seat for a tight seal. Replacement is necessary when the valve seat wears out, leading to leaks, or when the valve fails to open or close properly, disrupting the batching process. Its one-piece disc and stem design provides high flow rates and durability in demanding plant environments.

Key Features

• 12-inch nominal size for large-volume material handling.
• Wafer-style body for installation between ASME Class 125/150 flanges.
• One-piece disc/stem design for high strength and superior flow characteristics.
• Tongue-and-groove resilient seat provides bubble-tight shutoff and isolates the valve body from media.
• Extended neck allows for 2 inches of piping insulation.
• ISO 5211 top flange for direct mounting of actuators or manual handles.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. This valve is a direct replacement for 12-inch butterfly valves used on cement and fly ash silos or weigh hopper scale batchers in various concrete batch plants. It is a stock component on Stephens Mfg. batch plants and is also used by Vince Hagan. Compatible with equipment from OEMs like Con-E-Co, Erie Strayer, and Johnson Ross that utilize 12-inch butterfly valves for cement or water applications.

All measurements ± standard manufacturing tolerance.
