Air Valve - Double Solenoid

Air Valve - Double Solenoid

This double solenoid air valve is a critical component for controlling pneumatic cylinders and actuators within a concrete batch plant's air system. It is a 4-way, 5-port valve, meaning it has two solenoid coils to shift the valve's spool and direct airflow to extend and retract a double-acting cylinder. This type of valve is essential for operating components like aggregate batcher gates, providing reliable and fast actuation. Replacement is necessary when the existing valve fails to shift, leaks air, or the electrical coils burn out, leading to unresponsive or slow equipment.

Key Features

• Double solenoid design for positive electronic control in both directions of movement.
• 4-way, 5-port configuration for standard operation of double-acting pneumatic cylinders.
• Commonly used for controlling aggregate batcher gates on Vince Hagan and other concrete batch plants.
• Can be mounted on a sub-base for easy maintenance and replacement.
• Features a balanced spool design for consistent shifting regardless of pressure fluctuations.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Primarily used in the air control systems of concrete batch plants from OEMs like Vince Hagan, Con-E-Co, and Stephens. Specifically cited for use in Vince Hagan aggregate batcher applications.

All measurements ± standard manufacturing tolerance.
