Air Valve - Anti Overfill

Air Valve - Anti Overfill

This is a MAC Valves 45 Series air control valve, corresponding to Vince Hagan part number 430000. It is a 4-way, single solenoid valve with 1/4" ports, designed for use in the pneumatic circuits of concrete batch plants. Specifically, it is used for anti-overfill systems, where it directs compressed air to an actuator that closes a fill gate when a silo or hopper is full. This valve is a critical component for automated plant operation and preventing material spills. It features a 120V AC solenoid with 18-inch wire leads for electrical connection.

Key Features

• Genuine MAC Valves 45 Series air valve
• Single solenoid, 4-way, 2-position operation
• 120V AC, 60 Hz solenoid with 18" wire leads
• 1/4" NPT ports
• Used in Vince Hagan anti-overfill systems
• Maximum operating pressure of 120 PSI

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Specifically listed as the air valve for anti-overfill systems on Vince Hagan concrete batch plants. It is a direct replacement for Vince Hagan part number 430000.

All measurements ± standard manufacturing tolerance.
