Air Cylinder With Clevis

Air Cylinder With Clevis

This is a replacement double-acting air cylinder with a 4.5-inch bore, specifically used for controlling the aggregate gates on concrete batch plants. Activated by a solenoid valve, this cylinder provides the force needed to open and close bin gates, ensuring accurate and rapid weighing of sand and stone. It is built to withstand the harsh, dusty environment of a concrete plant and is a critical component for maintaining automated and precise batching operations. This part is necessary for replacing a worn or failing cylinder to prevent gate malfunctions and ensure consistent material flow.

Key Features

• Double-acting for powered movement in both extend and retract strokes
• 4.5-inch bore size for substantial force output
• Designed for use on concrete batch plant aggregate gates
• NFPA-interchangeable design for cross-compatibility
• Features a clevis mount for pivoting, articulated movement

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Primarily designed for use on the aggregate bin gates of various concrete batch plants. The 4.5-inch bore size is suited for applications requiring significant force to move aggregates, such as in bulk bag handling systems or large aggregate gate controls. Compatibility should be verified by matching bore, stroke, and mounting dimensions.

All measurements ± standard manufacturing tolerance.
