Plant Air Cylinder With Clevis and Pin - 4X10

Plant Air Cylinder With Clevis and Pin - 4X10

This is a replacement 4" x 10" air cylinder for concrete batch plants, often used for opening and closing aggregate bin gates or controlling valves on weigh hoppers. Constructed with corrosion-resistant materials like a nitro-carburized steel piston rod and aluminum components, it is built to withstand the harsh, dusty environment of concrete production. A new cylinder is needed when air leaks from the piston rod or from the exhaust on the air valve after a full extension, indicating seal failure. This specific model comes complete with a clevis and pin for mounting.

Key Features

• 4-inch bore size
• 10-inch stroke length
• Nitro-carburized piston rod for superior corrosion and wear resistance compared to standard chrome.
• Aluminum end caps and tube with hardcoat anodized ID for durability and low friction.
• U-cup rod and piston seals for zero leakage at various pressures.
• Designed for heavy-duty use in concrete plant applications like aggregate gates.
• Includes clevis and pin for installation.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits various concrete batch plant applications requiring a 4x10 air cylinder, most commonly for aggregate bin gates and weigh scale hopper gates on Vince Hagan, Stephens, and other compatible batch plant systems.

All measurements ± standard manufacturing tolerance.
