Air Cylinder - 3X8

Air Cylinder - 3X8

This is a replacement 3x8 air cylinder for use in concrete batch plant applications. With a 3-inch bore and an 8-inch stroke, it provides linear force to operate butterfly valves, aggregate bin gates, and aggregate weigh scale hopper gates. A new cylinder is needed when the existing one fails to hold pressure, leaks air from the rod or exhaust, or no longer extends and retracts properly, ensuring continued plant operation and accurate batching. This specific model features standard clevis mounts with 5/8" pins for attachment.

Key Features

• 3-inch bore diameter
• 8-inch stroke length
• Standard clevis mounts for installation
• Measures 17 inches from pin center to pin center when fully closed.
• Measures 25 inches from pin center to pin center when fully open.
• Designed for pneumatic linear actuation in concrete production.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Commonly used on concrete batch plants for operating butterfly valves, aggregate bin gates, and aggregate weigh scale hopper gates. This is an aftermarket replacement for Con-E-Co part number 145252 (heavy-duty mount version) and fits applications requiring a standard 3x8 clevis mount cylinder like part number 145282.

All measurements ± standard manufacturing tolerance.
