Plant Air Cylinder-W/Clev&Pin

Plant Air Cylinder-W/Clev&Pin

This is a replacement plant air cylinder used to operate gates and valves in concrete batching equipment. With a 3.5-inch bore and 8-inch stroke, it provides the linear force needed to open and close aggregate bin gates or butterfly valves. It is a critical component for automated plant operations, and replacement is necessary when air leaks are detected or the cylinder fails to extend or retract, causing operational downtime. This cylinder is built for heavy-duty applications and comes complete with clevis and pin mounts for installation.

Key Features

• 3.5-inch bore diameter
• 8-inch stroke length
• Tie-rod construction for durability
• Used for aggregate bins and butterfly valves on concrete batch plants
• 1-inch diameter piston rod
• Includes clevis and pin for mounting

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits Vince Hagan concrete batch plants and is used for operating components like aggregate bin gates and butterfly valves.

All measurements ± standard manufacturing tolerance.
