Plant Badger Mag Meter Magnetoflow 3"

Plant Badger Mag Meter Magnetoflow 3"

This Badger Meter M7600 is a 3-inch electromagnetic flow meter, also known as a mag meter, specifically used in the water systems of concrete batch plants to ensure precise and consistent mix designs. Because it operates on Faraday's Law of Induction and has no moving parts or obstructions in the flow tube, it provides accurate, repeatable measurements without pressure loss and requires minimal maintenance. This makes it a crucial component for replacing a faulty or inaccurate meter to maintain concrete quality, reduce waste, and ensure operational efficiency. The meter assembly includes the flanged flow tube and a separate, connected amplifier/transmitter in a NEMA 4X enclosure for processing and displaying flow data.

Key Features

• Electromagnetic design with no moving parts for minimal maintenance and no pressure loss.
• PTFE liner for chemical compatibility and high-temperature applications up to 212°F (100°C).
• Accuracy of ±0.5% ensures precise water measurement for consistent concrete quality.
• Durable carbon steel housing and ANSI 150# flanges for robust installation.
• Features a non-intrusive, open flow tube design.
• Separate cast aluminum NEMA 4X amplifier enclosure protects electronics from dust and water.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Designed for the water batching systems in concrete batch plants from major OEMs such as Con-E-Co, Vince Hagan, Stephens, and Johnson-Ross.

All measurements ± standard manufacturing tolerance.

Product descriptions are drafted with automated tools and reviewed as time allows. While we work to keep them accurate, specifications and fitment should be confirmed with a Customer Service specialist at 800-745-3414 before purchase. Found an error? Let us know and we’ll fix it.
