Dust Pinch Valve - 4

Dust Pinch Valve - 4

This is a complete 4-inch pinch valve assembly, identified by Vince Hagan part number 01-3995. It is installed at the discharge point of a central dust collector on a concrete batch plant to control the flow of collected cement dust. The valve operates using compressed air to open and close a flexible internal sleeve, making it ideal for handling abrasive materials. This assembly is a critical replacement part for maintaining the plant's dust control system and ensuring environmental compliance. The body is made of cast aluminum, and the assembly includes the necessary backing flanges for a complete installation.

Key Features

• Complete 4-inch pinch valve assembly
• Cast aluminum valve body
• Includes two steel backing flanges for installation
• Pneumatically (air) operated for reliable control of abrasive dust
• Direct cross-reference for Vince Hagan part 01-3995
• Used for dust control on concrete batch plants

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits Vince Hagan concrete batch plants on 4-inch cement silo fill lines or dust collector discharge points requiring part number 01-3995. While visually identical to valves used by other OEMs like Con-E-Co, this part number is specific to Vince Hagan.

All measurements ± standard manufacturing tolerance.
