Metal Work Single Solenoid Valve

Metal Work Single Solenoid Valve

This Metal Work single solenoid valve is a key component for controlling pneumatic actuators in concrete batch plants, such as air cylinders that operate aggregate gates and butterfly valves. It operates as a 5/2-way directional control valve, meaning it has five ports and two positions to extend and retract a cylinder. Conforming to the ISO 5599/1 standard for Size 1, it ensures interchangeability with other compliant valves and sub-bases. This valve is a necessary replacement part for maintaining the plant's automated air control systems, ensuring reliable and efficient operation. The manual override allows for testing and operation during power loss.

Key Features

• Conforms to ISO 5599/1, Size 1 mounting standard for interchangeability.
• 5/2-way, single solenoid with spring return operation.
• Maximum operating pressure of 10 bar (145 psi).
• Features a manual override for testing and emergency actuation.
• Operating temperature range of -10°C to +60°C.
• Designed for use with 30mm DIN 43650 Form A coils (sold separately).

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. This is a universal fit valve for any system using an ISO 5599/1 Size 1 sub-base. It is commonly used in the air control systems of concrete batch plants from manufacturers like Vince Hagan, Con-E-Co, and Stephens for operating gates and valves. The specific solenoid coil voltage (e.g., 120VAC, 24VDC) must be matched to the plant's electrical system.

All measurements ± standard manufacturing tolerance.
