Butterfly Valve Actuator 2"-4" Electric

Butterfly Valve Actuator 2"-4" Electric

This is a Bray Controls Series 70 electric actuator, easily identified by its distinctive red, low-profile, die-cast aluminum housing. It is engineered to automate quarter-turn valves, such as the 2-inch to 4-inch butterfly valves commonly used in concrete batch plants for controlling the flow of water or cement. This actuator is a necessary replacement part for maintaining automated plant operations, featuring a manual override handwheel for valve positioning during power loss or maintenance. Its robust construction and NEMA 4/4X rating ensure reliability in the harsh, dusty, and moist environments of concrete production facilities.

Key Features

• Manual declutchable override handwheel for emergency operation.
• High-visibility dome indicator for clear visual confirmation of valve position.
• Die-cast aluminum housing with polyester powder coating for corrosion and UV resistance.
• NEMA 4, 4X, IP65, and IP67 rated enclosure for outdoor and washdown durability.
• Directly mounts to valves with ISO 5211 standard mounting.
• Externally adjustable mechanical travel stops.
• On-Off or modulating control options available.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits 2-inch to 4-inch quarter-turn butterfly valves. Bray actuators are standard stock on Stephens Mfg. batch plants and are a common recommendation for cement and water service on various concrete batch plants. They are frequently used with 4-inch butterfly valves on the water metering system in ready-mix plants.

All measurements ± standard manufacturing tolerance.
