Plant Air Valve-Sgl L/Base

Plant Air Valve-Sgl L/Base

The MAC Valves 6311D-000-PM-111DA is a 4-way, 2-position single solenoid piloted spool valve used extensively in concrete batch plant air systems for functions like operating gates and controlling aeration. This valve is a critical component for automated plant operations, ensuring consistent and reliable shifting. It is a monostable valve with a spring return, meaning it reverts to its original position when de-energized. This specific model is a plug-in body type intended for use with a sub-base (sold separately), which contains all air and electrical connections for simplified maintenance and replacement. The solenoid features a non-burnout design on AC service for enhanced durability.

Key Features

• Single solenoid, spring return (monostable) operation.
• Operates on 110/120V AC, 50/60Hz power.
• Features a non-locking recessed manual operator.
• Plug-in body design for use with a sub-base.
• Patented MACSOLENOID with non-burnout feature on AC service.
• 4-port, 2-position (4/2-way) configuration.
• Checked accumulator for consistent shifting.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. This valve is used in the air control systems of various concrete batch plants, including those manufactured by Stephens Manufacturing, Con-E-Co, and Vince Hagan. It is typically used for operating butterfly valves, pinch valves, and aeration systems. The 'L/Base' in the CEPI description indicates it is used with a sub-base, which must have matching port sizes and wiring configurations.

All measurements ± standard manufacturing tolerance.
