Blue Level Motor 115Vac 50/60Hz 1Rpm

Blue Level Motor 115Vac 50/60Hz 1Rpm

This is a replacement synchronous motor for rotary paddle bin level indicators, commonly used in concrete batch plant silos and hoppers. The motor operates at 1 RPM and is powered by 115V AC. It drives a paddle that rotates until it is stopped by the presence of bulk material like cement or aggregate, which then triggers a level alert. This part is essential for replacing a failed or worn-out motor in a bin level indicator assembly to ensure accurate material level monitoring and prevent overfills or shortages.

Key Features

• Direct replacement for Con-E-Co bin level indicator motors.
• Operates at 1 RPM for standard paddle rotation speed.
• Powered by 115V AC, 50/60Hz.
• Features a motor shut-off function when the paddle is impeded to extend motor life.
• Includes pre-attached wire terminals for easier installation.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits rotary bin level indicators used in concrete batch plants from OEMs like Con-E-Co, Vince Hagan, and Stephens. It is the replacement motor for the Monitor Technologies Model KA bin indicator, which is used across many batch plant brands.

All measurements ± standard manufacturing tolerance.
