Air Cylinder

Air Cylinder

This is a plant air cylinder used to operate components like aggregate bin gates and butterfly valves on concrete batching plants. With a 4-inch bore and 12-inch stroke, it provides pneumatic force for consistent plant operation. This part is a critical replacement for worn or failed cylinders, ensuring that the automated functions of a batch plant continue to operate reliably and efficiently. It is a Nopak-style, tie-rod cylinder known for its durability in the demanding environment of concrete production.

Key Features

• 4-inch bore diameter
• 12-inch stroke length
• 1-inch diameter piston rod for heavy-duty application.
• Designed for use on concrete batch plant equipment.
• Tie-rod construction for durability and serviceability.
• Self-regulating cushions to eliminate shock at the end of the stroke.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits Vince Hagan concrete batch plants and is used for actuating components like aggregate gates and butterfly valves. Cross-references to Vince Hagan part number 02-2183.

All measurements ± standard manufacturing tolerance.
