Level Shaft Coupler Assembly

Level Shaft Coupler Assembly

This is a Springflex-style flexible shaft coupler designed for rotary paddle bin level indicators in concrete batch plants. It connects the indicator's drive motor to the paddle shaft, providing a flexible link that absorbs vibration and compensates for minor shaft misalignment. This reduces mechanical stress and wear on the sensor's driveshaft, prolonging the life of the bin level indicator. It is a critical replacement part for maintaining the accuracy and longevity of material level detection systems in silos and aggregate bins.

Key Features

• Flexible spring design absorbs shock and compensates for shaft misalignment
• Reduces mechanical load and stress on the bin level indicator's driveshaft
• Designed for top-mount rotary paddle bin level indicator applications
• Constructed from 306 Stainless Steel for durability and corrosion resistance.
• Includes coupling and pin for connection to paddle actuators.

Fits These Mixers

Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. Fits rotary paddle bin level indicators, such as the Monitor Technologies KA and KAX series, used in concrete batch plants. It is a common component in Con-E-Co, Vince Hagan, and Stephens batch plants for level indication in cement silos, fly ash silos, and aggregate bins.

All measurements ± standard manufacturing tolerance.

Product descriptions are drafted with automated tools and reviewed as time allows. While we work to keep them accurate, specifications and fitment should be confirmed with a Customer Service specialist at 800-745-3414 before purchase. Found an error? Let us know and we’ll fix it.
