Kimble Hydraulic Coil-Re Charge/Dischrg

Kimble Hydraulic Coil-Re Charge/Dischrg

This is a replacement solenoid coil for the hydraulic valve that controls the concrete mixer drum's charge and discharge operations. It is specifically used with Eaton 54 Series hydraulic pumps and fits on the Eaton 202603-000 cartridge valve. When energized, the coil creates a magnetic field that shifts the valve spool, directing hydraulic fluid to either charge (load) or discharge the mixer. This is a critical component for mixer operation, and replacement is necessary if the coil burns out or fails, rendering the charge/discharge function inoperable.

Key Features

• Activates the mixer drum's hydraulic charge/discharge function.
• Direct replacement for the coil on Kimble rear discharge mixers.
• Designed for use with Eaton 54 Series hydraulic pumps.
• Specifically fits Eaton cartridge valve model 202603-000.

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. Fits Kimble rear discharge mixers equipped with an Eaton 54 Series hydraulic pump system and an Eaton 202603-000 cartridge valve for the drum charge/discharge circuit.

All measurements ± standard manufacturing tolerance.
