Hydraulic Valve Cartidge - Charge Hopper

Hydraulic Valve Cartidge - Charge Hopper

This is a HydraForce SV10-20 series hydraulic cartridge valve, commonly used in the hydraulic control blocks of heavy equipment like concrete mixers. As a 2-way, normally closed valve, it functions as a blocking or load-holding device, making it ideal for controlling functions like chute locks or lifts. When de-energized, it blocks flow from port 2 to port 1, and when energized, the poppet lifts to open the flow path. This part is a critical replacement for failed or leaking valves to restore proper hydraulic function and prevent unintended equipment movement.

Key Features

• Functions as a 2-way, normally closed, solenoid-operated valve.
• Hardened steel seat for long life and low internal leakage (max 3 drops/min at 3000 psi).
• Designed for installation in an industry-common VC10-2 hydraulic valve cavity.
• Efficient wet-armature construction with continuous-duty rated coils (sold separately).
• Features a manual override option.

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. This valve is a direct replacement for the cartridge used in the hydraulic chute block on Kimble K2000 and K2100 series rear discharge mixers. It is a common component used by various OEMs for hydraulic load-holding and blocking functions.

All measurements ± standard manufacturing tolerance.
