Right Hand Rotary Paddle Indicator Blue Level
Level Indicator · Rotary Paddle
This is a WAM ILT series rotary paddle bin level indicator, identifiable by its blue plastic housing. It is used in concrete batch plants and other bulk solid storage applications to detect the presence or absence of materials like cement, sand, and aggregates. When the material level reaches the paddle, its rotation is blocked, triggering an electrical signal to a control system. As the material level falls, the paddle begins to rotate again. This allows for automated control of filling processes, preventing overflows and material outages.
Technical Specifications
Process Connection
G 1 1/2", G 1 1/4", G 2 1/2" options
Paddle Speed
1 RPM
Available Voltages
115V/230V AC, 24V/48V AC, 24V DC
Signal Delay
Approx. 1.3 seconds
Max Process Temperature
80 °C (176 °F)
Min Process Temperature
-20 °C (-4 °F)
Max Process Pressure
0.8 bar (11.6 psi)
Key Features
- Multivoltage design (AC and DC options available).
- Easy to install with threaded process connection.
- Reliable level measurement for bulk solids with densities from 0.5 t/m³ to 2 t/m³.
- Shaft and paddle made of stainless steel.
- IP65 rated enclosure.
- ATEX certified versions available for hazardous environments.
Fits These Mixers
Vince Hagan, CMW, Con-E-Co, Erie Strayer, Stephens, Donaldson Torit. This indicator is universally suitable for top or side mounting on bins, hoppers, and silos within concrete batch plants from manufacturers like Con-E-Co, Vince Hagan, and Stephens for monitoring levels of cement, fly ash, sand, and other aggregates.
All measurements ± standard manufacturing tolerance.
