Eaton Hydraulic Coil 12-Volt

Eaton Hydraulic Coil 12-Volt

This is a 12-volt DC replacement hydraulic solenoid coil for hydraulic control systems on Terex Advance and Oshkosh front discharge mixers. It is specifically designed to fit Eaton 54 Series pumps, actuating the valve cartridge for functions like drum start/stop or charge/discharge. Operators would need this part to replace a burnt-out or malfunctioning coil, which can cause unresponsive hydraulic controls. The coil's robust design includes an integrated diode for voltage spike protection and a Delphi Weather Pack connector, ensuring a secure and weather-resistant connection in the harsh environment of a concrete mixer.

Key Features

• Operates on a 12V DC electrical system.
• Features a Delphi Weather Pack connector for a secure, environmentally sealed connection.
• Includes an integrated diode to protect the electrical system from voltage spikes.
• Encapsulated design for protection against moisture, vibration, and contaminants.
• Direct replacement for specific Terex and Hydraforce part numbers.

Fits These Mixers

Terex, Terex Advance, Oshkosh. Primarily fits hydraulic control valves on Terex Advance and older Oshkosh front discharge mixers. It is commonly used on Eaton 54 Series hydraulic pumps, specifically with Eaton valve cartridge #202603-000 for drum control functions.

All measurements ± standard manufacturing tolerance.
