Oshkosh Hydraulic Chute Lift Cylinder

Oshkosh Hydraulic Chute Lift Cylinder

This is a double hydraulic chute lift cylinder, also known as a piggyback cylinder, designed for use on Oshkosh front discharge mixers. This assembly consists of two cylinders that work in tandem to provide a long stroke from a compact, retracted length, allowing for the lifting and positioning of the concrete chute. It is a critical component for the hydraulic system that controls the concrete placement, and replacement is necessary when the existing cylinder fails, leaks, or is damaged, to ensure safe and efficient operation of the mixer.

Key Features

• Piggyback design with two cylinders for a long extension from a short retracted length
• Durable steel construction for heavy-duty use in concrete applications

Fits These Mixers

Terex, Terex Advance, Oshkosh. Fits Oshkosh S-Series front discharge concrete mixers. It is advisable to verify the part number with the specific mixer's manual for accurate fitment.

All measurements ± standard manufacturing tolerance.
