Schwing Hydraulic Chute

Schwing Hydraulic Chute

This is a replacement solenoid-operated hydraulic cartridge valve used in the hydraulic control system of a concrete mixer truck. The valve directs hydraulic fluid to raise, lower, or swing the discharge chute. It features a DIN-style electrical connector and a manual override pin. This part is essential for restoring proper function to the chute's hydraulic controls when the original valve fails due to electrical issues or internal contamination.

Key Features

• Solenoid-operated for electrical control
• Cartridge design for installation into a hydraulic manifold
• Includes manual override pin for diagnostics and emergency operation
• Features a common DIN-style electrical connector

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. While the product name suggests a Schwing application, this style of valve is common across various concrete mixer brands for hydraulic chute control. Visual confirmation against the existing part is recommended. It is listed as a component for Schwing concrete pumps and may be used on their truck mixers or on other brands like McNeilus that use similar hydraulic systems.

All measurements ± standard manufacturing tolerance.
