Schwing Trailer Latch Pin Brkt

Schwing Trailer Latch Pin Brkt

This product is a specialized wear plate or bracket for the latch pin assembly on a rear discharge concrete mixer truck. It is designed to be installed within the lift axle or tag axle system, providing a durable, low-friction contact surface for the axle's locking hook or pin. Its non-metallic construction suggests it is a sacrificial wear item, designed to be replaced during maintenance to prevent wear on more critical steel components of the axle and frame. This part is essential for maintaining the proper function of the axle latching system, which secures the lift axle in the raised or lowered position.

Key Features

• Shaped with a distinct curve on one side to guide or seat a latch pin/hook.
• Features a central mounting hole for attachment.
• Likely constructed from a high-wear, non-metallic polymer or phenolic material to act as a sacrificial rub plate.
• Designed for the high-stress environment of a mixer's lift axle assembly.

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. This part is contextually identified for use in the lift axle or tag axle latching systems of rear discharge concrete mixers, such as the McNeilus Bridgemaster or Con-Tech BridgeKing trailer systems. The original product name 'Schwing Trailer Latch Pin Brkt' is likely a misnomer, as the part's application aligns with McNeilus and Con-Tech axle assemblies.

Product descriptions are drafted with automated tools and reviewed as time allows. While we work to keep them accurate, specifications and fitment should be confirmed with a Customer Service specialist at 800-745-3414 before purchase. Found an error? Let us know and we’ll fix it.
