Advance Hydraulic Cylinder Foldback Assembly

Advance Hydraulic Cylinder Foldback Assembly

This is a replacement hydraulic cylinder for the power chute fold assembly on Terex Advance front discharge mixers. It is a critical component for hydraulically folding and unfolding the chute sections, allowing for efficient and safe operation. This cylinder is necessary for replacing a damaged or leaking unit to restore proper function to the mixer's chute system. The cylinder has a 1.5-inch bore, a 6-inch stroke, and a 0.75-inch rod.

Key Features

• Designed for the hydraulic chute fold assembly
• 1.5-inch bore diameter
• 6-inch stroke length
• 0.75-inch rod diameter
• 13-inch closed length (center of pin to center of pin)
• Features 1/4-inch NPTF ports

Fits These Mixers

Terex, Terex Advance, Oshkosh. Fits the hydraulic chute fold-down assembly on Terex Advance front discharge concrete mixer trucks. Compatibility with specific models and years has not been confirmed.

All measurements ± standard manufacturing tolerance.

Product descriptions are drafted with automated tools and reviewed as time allows. While we work to keep them accurate, specifications and fitment should be confirmed with a Customer Service specialist at 800-745-3414 before purchase. Found an error? Let us know and we’ll fix it.
