McNeilus Chute Pivot Clamp Plate

McNeilus Chute Pivot Clamp Plate

This chute pivot clamp plate is a critical component of the rear pivot and chute lock assembly on McNeilus rear discharge mixers. It functions as a brake plate, securing the discharge chute to prevent it from swinging freely during transit or when positioned for a pour. This heavy-duty plate is a direct replacement for worn or damaged original parts, ensuring the safe and stable operation of the chute system. Replacement is necessary when the original plate is cracked, bent, or excessively worn, which can compromise the chute's locking ability.

Key Features

• Also known as a disc rear brake plate
• Component of the chute lock and pivot assembly
• Secures the chute's position for safe operation
• Direct replacement for OEM part
• Length: 20.25 inches
• Width: 11.75 inches
• Height: 0.5 inches

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. Fits McNeilus rear discharge mixers as a component of the chute pivot and chute lock assembly.

All measurements ± standard manufacturing tolerance.
