McNeilus Hydraulic Chute Cyl-7/8"-N/S

McNeilus Hydraulic Chute Cyl-7/8"-N/S

This single-acting hydraulic chute lift cylinder is a direct replacement component for McNeilus rear discharge concrete mixers. It features a 15.25-inch stroke and 7/8-inch eyelet holes on both ends for secure mounting to the chute pivot assembly. Operating on a power-up/gravity-down hydraulic circuit, it provides the necessary force to raise and lower the main discharge chute during concrete pouring operations. Replacing a leaking or failing chute cylinder ensures safe, responsive chute control and prevents hydraulic fluid loss on the job site.

Key Features

• Single-acting hydraulic design (power up, gravity down) for efficient chute control
• 7/8-inch mounting eyelets on both the base and rod ends for standard McNeilus fitment
• Direct OEM replacement for McNeilus/MTM part numbers 1139840 and 107615
• Heavy-duty steel construction to withstand harsh ready-mix concrete environments

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. Fits McNeilus rear discharge concrete mixers equipped with single-acting hydraulic chute lift systems. Compatible as a direct replacement for McNeilus/MTM systems using 7/8-inch pivot pins.

All measurements ± standard manufacturing tolerance.
