McNeilus 3-Place Manifold Body

McNeilus 3-Place Manifold Body

This 3-place manifold body is a critical component of the air control system on McNeilus Bridgemaster and Standard rear discharge mixers. It serves as the central mounting base for up to three MAC 92 Series pneumatic solenoid valves, such as the chute lock (1138152), charge hopper (1138153), and auxiliary axle (1138154) valves. By consolidating the air supply into a single block, this manifold reduces plumbing complexity and ensures consistent air pressure distribution to the mixer's operational controls. It is an exact OEM replacement part designed for plug-in style valves.

Key Features

• 3-station design accommodates up to three individual pneumatic control valves
• Compatible with MAC 92 Series plug-in style solenoid valves
• Consolidates pneumatic plumbing to reduce leaks and simplify the control box layout
• Precision-machined internal passages for consistent air pressure distribution
• Direct OEM replacement for McNeilus mixer air systems

Fits These Mixers

McNeilus, Con-Tech, CBMW, Kimble. Fits McNeilus Bridgemaster and Standard rear discharge mixers. Mounts inside the pneumatic control box to support valves for the chute lock, hopper lift, chute swing, and pusher/tag axles.

All measurements ± standard manufacturing tolerance.
