ZF Gearbox Nut Flange

ZF Gearbox Nut Flange

This genuine ZF slotted nut (M100 x 1.5 thread) is specifically designed to secure the output flange on ZF concrete mixer gearboxes, including the P-5300, P-6300, P-7300, and PK-7500 series. As a critical fastening component in the drum drive system, it ensures the output flange remains tightly seated under the extreme rotational loads of a concrete mixer. Replacing this nut is essential during gearbox rebuilds or when servicing the output flange seals and bearings to maintain proper torque and prevent fluid leaks or mechanical play.

Key Features

• Precision-machined M100 x 1.5 metric thread for exact fitment
• Slotted design allows for secure tightening using a specialized hook spanner (ZF tool 5870 401 067)
• Secures the output flange to the main gearbox assembly
• Manufactured from high-strength steel to withstand high-torque mixer drum applications

Fits These Mixers

ZF, Rex, PMP, Challenge, Bonfiglioli. Fits ZF concrete mixer gearboxes including models P-5300, P-6300, P-7300, and PK-7500. Commonly found on McNeilus and other front/rear discharge mixers utilizing ZF drum drives.

All measurements ± standard manufacturing tolerance.
